Technical Specifications
Yellow Green - J/JU
Elevate your displays with vivid hues tailored to meet your unique display requirements.
| Parameter |
Symbol |
Condition |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
Vf |
If=10mA |
1.8 |
|
2.4 |
V |
| Reverse Voltage |
Vr |
Ir=10uA |
5 |
|
|
V |
| Luminous Intensity |
Iv |
If=10mA |
30 |
|
40 |
mcd |
| Spectrum Width Of Half Value |
△λ |
If=10mA |
|
20 |
|
nm |
| Wavelength |
Dλ |
If=10mA |
569 |
|
574 |
nm |
Amber/Yellow - Y
Choose this warm, inviting color to craft displays that command attention and exude warmth.
| Parameter |
Symbol |
Condition |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
Vf |
If=10mA |
1.8 |
|
2.5 |
V |
| Reverse Voltage |
Vr |
Ir=10uA |
5 |
|
|
V |
| Luminous Intensity |
Iv |
If=10mA |
60 |
|
80 |
mcd |
| Spectrum Width Of Half Value |
△λ |
If=10mA |
|
20 |
|
nm |
| Wavelength |
Dλ |
If=10mA |
585 |
|
595 |
nm |
Absolute Maximum Ratings (Ta=25ºC)
Robust performance parameters defining the remarkable capabilities of our LED display.
| Parameter |
Symbol |
Ratings |
Unit |
| Forward Current (per dice) |
Ipm |
20 |
mA |
| Reverse Voltage (per dice) |
Vr |
5 |
V |
| Power Dissipation (per dice) |
Pm |
80 |
mW |
| Operating Temperature Range |
Topr |
-40~+85 |
ºC |
| Storage Temperature Range |
Tstg |
-40~+85 |
ºC |
| Solder Temperature (≤3 seconds) |
Th |
260 |
ºC |
Manufacturer Profile
Shenzhen Guangzhibao Technology Co., Ltd. (BRAND: LIGHT-BO), established in 2006, symbolizes excellence in OEM and ODM services. As an ISO 9001:2015 certified leader, our legacy of over 15 years is marked by quality and innovation.
LIGHTBO propels clients to new heights with high-quality, cost-effective custom solutions, reducing expenses and fortifying competitive advantages globally.
Product Applications
7 Segment LED Display, Customized LED Display, Numeric LED Display, Dot Matrix LED Display: Our innovative products find applications in home appliances, temperature and humidity indicators, refrigerator controllers, thermostats, and heating and cooling systems, showcasing our commitment to performance.
Frequently Asked Questions
Are you a trading company or manufacturer?
We are original manufacturer with more than 20 years experience in optoelectronic LED displays.
What are your main products?
Our main products include 7 Segment LED display, SMD LED Display, Dot matrix LED Display, Arrow LED display, Custom Design LED Display, LED light bar, Through hole LED, SMD LEDs, LED Backlights, and more.
What is your MOQ?
Our MOQ is 1000 pcs. We can also accept sample orders and small orders with quantity less than our MOQ.
Can I get samples for testing before placing an order?
Yes. We can provide 5-10 free samples for your testing, but the freight cost will be borne by the customer.
How long is your delivery time?
Delivery time: About 10-20 days; According to order quantity and raw materials. If you have urgent order and we have raw materials in stock, we can adjust our production plan to make it ready within 7-10 days.
What are your payment terms?
We accept bank transfer, T/T, Western Union and Paypal with small amount. Details of payment methods can be negotiable.
Can you quote FOB prices?
Yes. We can quote prices based on incoterms EXW, FOB, CIF, DDP.
How can I get your catalogue and price list?
Please let us know your email address or contact us from website directly for our catalogue and price list.
Can I negotiate the prices?
Yes, we may consider discounts for bulk orders.
How much will the shipping charges be?
It depends on the size of your shipment and the method of shipping. We will provide the charge to you as requested.
Can you do custom design products?
Yes, OEM & ODM services are available. We can customize the sizes, LED color and functional icons according to your requirements.
If I send my design, can you make it exclusively for me?
Yes, we will not show it or sell to others without your authorization.
What is the samples lead time for customized products?
Samples lead time will be about 20-25 working days after receiving mold cost and mold drawing approval from customers.
What are your shipping methods?
We usually ship goods by DHL, FEDEX, UPS, EMS, BY AIR, BY SEA, etc. You can also choose other methods that work best for you.
How do you ensure product quality?
We are ISO 9001 QMS certified manufacturers with more than 20 years experience. We conduct twice 100% testing for all products before shipment.
